GC Autosampler Syringes for CTC Analytics

  • Fixed Needle Syringes
  • Removable Needle Syringes
  • Single Gauge Syringes
  • Gas Tight Syringes
  • Replacement Needles and Plungers
  • Matched to CTC Holders to Ensure Proper Fit and Reliable Functioning
Guaranteed Compatibility with Agilent, Varian, Shimadzu, PerkinElmer, and More.

Extra-Long-Life
Multipliers & Filaments

Manufactured
in the USA

Increase Instrument
Uptime

Industry-Leading
Linearity

Used by OEMs in
Premium Instruments

Late Order
Cutoff Time

Syringes with Fixed Needle

Accuracy and Reproducibility ± 1 % (dispensed volume) (± 2 % for 0.5 μL syringes)
Borosilicate Glass Barrel Outer Diameter (OD) 0.5 μL to 100 μL = 6.5 mm, 250 μL and 500 μL = 8 mm 1 mL = 7.6 mm, 2.5 mL = 9.7 mm
Scale Length 0.5 μL = 27.05 mm, 5 μL and 10 μL = 54.1 mm, 25 μL to 2.5 mL = 60 mm
Specifications of the following syringes are matched to CTC holders to ensure proper fit and reliable functioning.
Volume Needle Length (mm) Needle Gauge Needle OD/ID (mm) Tip Style Syringe Code Repl. Plunger P/N 6/pk Syringe P/N 1/pk Syringe P/N
Fixed Needle - Single Gauge
5 μL 50 26 0.47/0.11 Cone 5F-CTC-5/0.47C - - 1700
5 μL 50 23 0.63/0.11 Cone 5F-C/T-5/0.63C - - 1981
5 μL 50 26 0.47/0.11 Cone 5F-C/T-5/0.47C - - 1982
10 μL Gas Tight 50 26 0.47/0.11 Cone 10F-C/T-GT-5/0.47C 31803 2976 2977
10 μL 50 26 0.47/0.11 Cone 10F-CTC-5/0.47C - - 2700
10 μL 50 26 0.47/0.11 Bevel 10F-CTC-5/0.47BV - - 2705
10 μL 50 23 0.63/0.11 Cone 10F-C/T-5/0.63C - 2971 2981
10 μL Gas Tight 50 22 0.72/0.175 Side Hole 10F-CTC-GT-5/0.72H 31803 - 2983
10 μL Gas Tight 50 23 0.63/0.11 Cone 10F-C/T-GT-5/0.63C 31803 2972 2987
25 μL Gas Tight 50 26 0.47/0.11 Cone 25F-CTC-GT-5/0.47C 318922 - 3700
25 μL 50 26 0.47/0.11 Cone 25F-C/T-0.47C - - 3980
25 μL Gas Tight 50 23 0.63/0.24 Cone 25F-C/T-GT-0.63C 31817 - 3987
100 μL Gas Tight 50 26 0.47/0.11 Cone 100F-CTC-GT-5/0.47C 318261 - 5700
100 μL Gas Tight 50 23 0.63/0.24 Cone 100F-C/T-GT-0.63C 318261 - 5335
250 μL Gas Tight 50 26 0.47/0.25 Cone 250F-CTC-GT-5/0.47C 318926 - 6700
500 μL Gas Tight 50 26 0.47/0.25 Cone 500F-CTC-GT-5/0.47C 318928 - 7700
1 mL 56 26 0.47/0.15 Side Hole 1MF-CTC-GT-HS-5/0.47H 318441 - 8135
1 mL 56 23 0.63/0.15 Side Hole 1MF-CTC-GT-HS-5/0.63H 318441 - 8130
2.5 mL 56 26 0.47/0.15 Side Hole 2.5MF-CTC-GT-HS-5/0.47H 318451 - 8635
2.5 mL 56 23 0.63/0.15 Side Hole 2.5MF-CTC-GT-HS-5/0.63H 318451 - 8630

Syringes with Removable Needle

Volume Needle Length (mm) Needle Gauge Needle OD/ID (mm) Tip Style Syringe Code Repl. Needle P/N Repl. Plunger P/N 1/pk Syringe P/N
Removable Needle - Single Gauge
0.5 μL 50 26 0.47/0.11 Cone 0.5BNR-C/T-0.47C 33770 - 490
0.5 μL 50 23 0.63/0.11 Cone 0.5BNR-C/T-0.63C 33772 - 492
5 μL 50 23 0.63/0.11 Cone 5R-C/T-0.63C 36011 - 1984
10 μL Gas Tight 51.5 23 0.63/0.11 Cone 10R-C/T-GT-5.15/0.63C 37013 318121 2965
10 μL 50 26 0.47/0.11 Cone 10R-C/T-5/0.47C 37010 - 2982
10 μL 50 23 0.63/0.11 Cone 10R-C/T-0.63C 37787 - 2984
10 μL Gas Tight 50 26 0.47/0.11 Cone 10R-C/T-GT-0.47C 37787 318121 2985
25 μL Gas Tight 50 26 0.47/0.175 Side Hole 25R-C/T-GT-0.47H 38749 31816 2988
25 μL Gas Tight 50 22 0.72/0.375 Side Hole 25R-C/T-GT 0.72H 38420 31816 2989
100 μL Gas Tight 50 26 0.47/0.2 Cone 100R-C/T-GT-0.47C 38732 31826 5333
100 μL 50 23 0.63/0.24 Side Hole 100R-C/T-GT-0.63H 38736 31826 5337
100R-C/T-GT-0.47C SYRINGE
Item number 005333
135.00 135.0 USD
100F-C/T-GT-0.63C 100UL SYRINGE
Item number 005335
133.00 133.0 USD
