5 - 10 μL Metal Plunger Syringes


5 - 10 μL Metal Plunger Syringes

  • Standard Plunger Protection Syringes
  • SuperFlex™ Syringes
  • Guided Plunger Syringes
  • Available with Fixed and Removable Needles
  • Replacement Needles
Guaranteed Compatibility with Agilent, Varian, Shimadzu, PerkinElmer, and More.

Extra-Long-Life
Multipliers & Filaments

Manufactured
in the USA

Increase Instrument
Uptime

Industry-Leading
Linearity

Used by OEMs in
Premium Instruments

Late Order
Cutoff Time

General Purpose Manual Syringes | 5 - 10 μL Metal Plunger​

Accuracy and Reproducibility ± 1 % (dispensed volume)
Borosilicate Glass Barrel Outer Diameter (OD) 6.5 mm (guided plunger syringes 8 mm)
Scale Length 54.1 mm

Standard Plunger Protection Syringes

Volume Needle Length (mm) Needle Gauge OD (mm) ID (mm) Tip Style Syringe Code Replacement Needle P/N Syringe P/N
Fixed Needle
5 μL 50 26 0.47 0.11 Bevel 5F - 1000
5 μL 70 26 0.47 0.11 Bevel 5F-7 - 1002
5 μL 42 23 0.63 0.11 cONR 5F- 4.2/0.63C - 8139
10 μL 50 26 0.47 0.11 Bevel 10F - 1/pk - 002000 6/pk - 002030 10/pk - 002033 25/pk - 002035
10 μL 70 26 0.47 0.11 Bevel 10F-7 - 2003
10 μL 50 26 0.47 0.11 Cone 10F-5C - 2005
10 μL 115 26 0.47 0.11 Bevel 10F-11.5 - 2007
10 μL 42 23 0.63 0.11 Cone 10F-4.2/0.63C - 2839
Removable Needle
5 μL 50 26 0.47 0.11 Bevel 5R 36110 1050
10 μL 50 26 0.47 0.11 Bevel 10R 37110 1/pk - 002050 6/pk - 002080
10 μL 70 26 0.47 0.11 Bevel 10R-7 37130 2055

Guided Plunger Syringes

Guided plunger syringes are the most rugged syringe available, making them perfect for industrial environments.

Volume Needle Length (mm) Needle Gauge OD (mm) ID (mm) Tip Style Syringe Code Replacement Needle P/N Syringe P/N
Fixed Needle
5 μL 50 26 0.47 0.11 Bevel 5FX - 1100
10 μL 50 26 0.47 0.11 Bevel 10FX - 1/pk - 002100 6/pk - 002130
10 μL 50 26 0.47 0.11 Cone 10FX-5C - 1/pk - 002105 6/pk - 002133
10 μL 50 23 0.63 0.11 Cone 10FX-5/0.63C - 6/pk - 002135
Removable Needle
10 μL 50 26 0.47 0.11 Bevel 10RX 37110 6/pk - 002180

SuperFlex™ Syringes

The virtually indestructible Titanium Nickel alloy plunger of the SuperFlex™ Syringes is ideal for student use.

Volume Needle Length (mm) Needle Gauge OD (mm) ID (mm) Tip Style Syringe Code Replacement Needle P/N Syringe P/N
Fixed Needle
5 μL 50 26 0.47 0.11 Bevel 5F-GP - 1400
10 μL 50 26 0.47 0.11 Bevel 10F-GP - 2400
Removable Needle
5 μL 50 26 0.47 0.11 Bevel 5R-GP 36110 1450
5 μL 50 26 0.47 0.11 Bevel 5R-GPS 37110 001495*
10 μL 50 26 0.47 0.11 Bevel 10R-GP 37110 2450
* Short half scale syringe (scale length 27 mm)
